    Appli Parts APAC-340120 Heavy Duty Contactor 3 Poles 40A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929
    Appli Parts APAC-340120 Heavy Duty Contactor 3 Poles 40A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929

    Appli Parts APAC-340120 Heavy Duty Contactor 3 Poles 40A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929

    SKU
    G0323.4031
    Tags ac contactor hvac contactor c130a contactor contactor 24v coil mini contactor contactors 220 volt hvac carrier ac contactor heat pump contactor 1 pole conti pro contact lightning contactor r8242a 1032 mars contactor 24v coil
    Description
    Appli Parts APAC-340120 Heavy Duty Contactor 3 Poles 40A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929
    Application: Heavy-duty 3 Poles 40A 120V coil contactor for air conditioners, heat pumps, water pumps, refrigeration systems, and electric motors. Universal replacement for HVAC and industrial applications.
    Ratings: 3 Poles 40A full load (FLA). Locked rotor (LRA): 240/277V 240A, 480V 200A, 600V 120A, UL Certified E476929 for reliable operation and long service life.
    Coil Data: Resistance 180 Ohm (DC measurement, coil 120V). Switching capacity: 50A (resistive load: FLA 40A, LRA: 240/277V at 240A, 480V at 200A, 600V at 120A). Nominal Inrush 65VA at 50Hz / 60VA at 60Hz, Nominal Sealed 7.5VA at 50Hz / 6VA at 60 Hz.
    Electrical Performance: Maximum Pick-Up 88V, Minimum Drop-Out 20/70V, Maximum Voltage 132V. Insulation Resistance: Class B, 130C, for enhanced safety and reliability.
    Certified Quality Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacement.

    Weight : 0.98 LBR
    Volume : 0.01880787 FTQ
    Model : APAC-340120
    UPC-EAN : 814245022044

    G0323.4031
    New

    Data sheet

    Product Characteristic

    Application: Heavy-duty 3 Poles 40A 120V coil contactor for air conditioners, heat pumps, water pumps, refrigeration systems, and electric motors. Universal replacement for HVAC and industrial applications.
    Ratings: 3 Poles 40A full load (FLA). Locked rotor (LRA): 240/277V 240A, 480V 200A, 600V 120A, UL Certified E476929 for reliable operation and long service life.









    Coil Data: Resistance 180 Ohm (DC measurement, coil 120V). Switching capacity: 50A (resistive load: FLA 40A, LRA: 240/277V at 240A, 480V at 200A, 600V at 120A). Nominal Inrush 65VA at 50Hz / 60VA at 60Hz, Nominal Sealed 7.5VA at 50Hz / 6VA at 60 Hz.
    Electrical Performance: Maximum Pick-Up 88V, Minimum Drop-Out 20/70V, Maximum Voltage 132V. Insulation Resistance: Class B, 130C, for enhanced safety and reliability.









    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C340B / 17436 / 42CF35AFBCC / 453AD3ABB / C25DNF340A / GDP4031 / HCCY3XT04CJ303 Confirm cross-reference and specifications before replacem
    Model
    APAC-340120
    UPC-EAN
    814245022044
    Sales Unit
    EA
    Origin
    China
    US Tariff Code
    8536.49.0065
    Base Unit
    EA
    Dimensions
    5 x 5 x 5

    Specific References

    UPC
    814245022044
    MPN
    APAC-340120
